China Expandable Container House Manufacturer, Supplier
Expandable container house is widely used in all industries of life, oil fields, mines, infrastructure, bridge construction, although it is a temporary building, we always puts the safety of the house and users first, so we are equipped with designed by professional engineers who care about every detail, our flat pack containers produced with high quality and safety standards constitute the most popular living spaces in modular construction.
Expandable house is detachable and reusable, its size is also very flexible, from 20ft to 40ft or even larger space, several units can be assembled at will, 5 people can install 6 units (106 square meters)per day. Besides the container house, we also supply an electricity system and plumbing system. Before it was used, you don’t need to purchase anything else.
Details
Product features
- Compared with the traditional building, easier to install, cheap, time-saving, labor cost, and transportation cost saving.
- Compared with other manufacturers, high-quality materials, sturdy structure.
- Layouts can be one living room, living room with one toilet, living room with one toilet and one bedroom, living room with one toilet and two bedrooms or three bedrooms.
- With air-conditioner socket,distribution box,switch,led light,exhaust fan.
- Optional fittings: terrace, roof and foot support, wallpaper and clothing, etc.
Usage:
Expandable container house is widely used in all situations, such as office, living room, meeting room, dormitory, shop, toilet, storage, kitchen, shower room, and so on. In addition, the house layout can be customized according to your requirements. Besides, we can change the layout by an add a partition wall and facilities like a toilet, it could be directly used when it arrived at the site.
| 20FT Basic Information | 20FT Basic Information | 6300*5900*2500mm |
| Internal size | 6140*5670*2240mm | |
| Package size | 2200*5900*2500mm | |
| 40FT Basic Information | External size | 6300*11800*2500mm |
| Internal size | 6300*11800*2500mm | |
| Package size | 6140*11570*2240mm | |
| Frame Structure | Bottom girder | Galvanized square pipe 100*100*2.0MM Q235 Galvanized square pipe 80*40*1.5MM Q235 Galvanized square pipe 150*100*2.0MM Q235 Galvanized square pipe 150*150*2.0MM Q235 |
| Top girder | Galvanized square pipe 150*100*2.0MM Q235 Galvanized square pipe 100*50*2.0MM Q235 Galvanized square pipe 80*80*2.0MM Q235 Galvanized square pipe 60*40*2.0MM Q235 |
|
| upright | Galvanized square pipe 150*150*2.0MM Q235 | |
| subframe | p80*50*1.2MM Q235 Galvanized square pipe 80*40*1.5MM Q235 Galvanized square pipe 80*60*1.5MM Q235 Galvanized square pipe 120*60*1.5MM Q235 Galvanized square pipe 60*40*2.0MM Q235 |
|
| hinge | Galvanized thickening hinge Q235 | |
| Flooring | Intermediate floor | 18mm cement floor |
| Side floor | 15mm bamboo plywood | |
| Plastic floor | 16mm plastic floor | |
| Insulation Wall | Outer wall | “75mm sandwich sandwich panel, color roll on both sides 0.25 (rock wool 80kg/m³, EPS, polyurethane optional) The standard sandwich material is 10kg/m³EPS” |
| Cut off | 50mm sandwich sandwich plate, color steel base plate double side 0.25. The insulation material is the same as ↑ above | |
| Main roof and side roof | 50mm sandwich sandwich plate, color steel base plate double side 0.25. The insulation material is the same as ↑ above | |
| Electrical System | argument | 1, standard with national standard wire; Inlet line 6², air conditioning socket 4², general socket 2.5², lighting 1.5². (Can be customized according to the country to meet the certification requirements circuit) 2, circuit breaker system, 2P32 leakage protector 1 /2P32A air switch 2. 3, lighting; LED ceiling lights *6. 4, socket; Standard three-hole socket (socket standard can be configured according to customer requirements) |
| Door And Window System | Entrance door | Standard steel double doors (can be customized KFC, aluminum alloy door) |
| Steel door | 50 jack type steel door | |
| window | Standard plastic steel double glass sliding window (can be customized high-end broken bridge aluminum window and aluminum alloy sliding window) 930*900*6（40Ft is 8）; 500*500*1 |
|
| Bathroom (optional) | Sanitary ware material | Toilet door Glass door, integrated shower (8㎜ tempered glass sliding door), toilet, wash basin, shower head |
Advantage:
1.Ready for use,without any assemble work.
2.Convenient for moving,transporting,water cleaning.
3.Service life:30 years
4.Good waterproof, sound-insulated,heat preservation,environmental protection.
5.The layout is customized design.
6.International standard can be put on other shipping container.
7.Beautiful appearance,different colors.
For Product:
1. What tools and equipment are required for container installation?
Crane, hand saw, hand drill, hex screwdriver, rubber hammer, utility knife, hole saw, non-slip gloves, glass glue gun, tape measure, medical kit, marker, ladder, level.
For Service:
1. Can you guide the installation?
Yes, my company has a professional installation team guidance. What is the quantity of your purchase this time? If the quantity is more than 300 units, we can guide the installation for free, you only need to be responsible for the engineer’s visa, air tickets, accommodation expenses.
